MAX PV Input Power:  10400

Rated PV Input Voltage (V): 370 (125~500)

Start-up Voltage (V): 125

MPPT Voltage Range (V): 150-425

Full Load DC Voltage Range (V): 200-425

PV Input Current (A): 26+26

Max. PV ISC (A): 34+34

Number of MPPT / Strings per MPPT: 2/2+2

Rated AC Output or UPS Power (W): 8000

Max. AC Output Power (W): 8800

AC Output Rated Current (A): 36.4

Max. AC Current (A): 40

Max. Continuous AC Passthrough (A): 50

Peak Power (on grid): 2 time of rated power, 10 S

Power Factor: 0.8 leading to 0.8 lagging

Output Frequency and Voltage: 50/60Hz; L/N/PE 220/230Vac (single phase)

Grid Type: Single Phase

DC injection current (mA): THD<3% (Linear load<1.5%)

Battery Voltage Range (V): 40~60V

Max. Charging Current (A): 190

Max. Discharging Current (A): 190

Number of battery input: YES

Charging Curve: 3 Stages / Equalization

Charging strategy for lithium-ion battery: Self-adaption to BMS

Max. Efficiency: 97.6%

Euro Efficiency: 96.5%

MPPT Efficiency: >99%

PV Input Lightning Protection, Anti-islanding Protection, PV String Input Reverse Polarity Protection,
Insulation Resistor Detection, Residual Current Monitoring Unit, Output Over Current Protection,
Surge protection

Grid Regulation: EN50549,AS4777.2,VDE0126,IEC61727,VDEN4105,G99,NBT32004,CEI0-21，
NRS097,NBR16149/16150,RD1699

Safety EMC / Standard: IEC62109-1/-2, EN61000-6-1,EN61000-6-2,EN61000-6-3,EN61000-6-4

Operating Temperature Range (℃): range -45~60℃, >46℃ derating

Cooling: Natural cooling

Noise (dB): <30 dB

Communication with BMS: RS485; CAN

Weight (kg): 32

Size (mm): 420W×670H×233D

Protection Degree: IP65

Installation Style: Wall-mounted

Warranty: 5 years
